Extended Defects in Semiconductors

Electronic Properties, Device Effects and Structures

D. B. Holt (Imperial College of Science, Technology and Medicine, London) B. G. Yacobi (University of Toronto)

$86.95

Paperback

Not in-store but you can order this
How long will it take?

QTY:

English
Cambridge University Press
07 August 2014
The elucidation of the effects of structurally extended defects on electronic properties of materials is especially important in view of the current advances in electronic device development that involve defect control and engineering at the nanometer level. This book surveys the properties, effects, roles and characterization of extended defects in semiconductors. The basic properties of extended defects (dislocations, stacking faults, grain boundaries, and precipitates) are outlined, and their effect on the electronic properties of semiconductors, their role in semiconductor devices, and techniques for their characterization are discussed. These topics are among the central issues in the investigation and applications of semiconductors and in the operation of semiconductor devices. The authors preface their treatment with an introduction to semiconductor materials and conclude with a chapter on point defect maldistributions. This text is suitable for advanced undergraduate and graduate students in materials science and engineering, and for those studying semiconductor physics.

By:   ,
Imprint:   Cambridge University Press
Country of Publication:   United Kingdom
Dimensions:   Height: 244mm,  Width: 170mm,  Spine: 33mm
Weight:   1.010kg
ISBN:   9781107424142
ISBN 10:   1107424143
Pages:   644
Publication Date:
Audience:   Professional and scholarly ,  Undergraduate
Format:   Paperback
Publisher's Status:   Active
1. Semiconducting materials; 2. An introduction to extended defects; 3. Characterization of extended defects in semiconductors; 4. Core structures and mechanical effects of extended defects specific to semiconductors; 5. The electrical, optical and device effects of dislocations and grain boundaries; 6. Point defect materials problems.

David Holt is an Emeritus Professor in the Department of Materials at Imperial College, London. He obtained his doctorate in Physical Metallurgy from the University of Birmingham, UK, in 1956, after which he held a number of academic positions over five years in the physics department at the University of the Witwatersrand, South Africa, before moving to the Department of Metallurgy at Imperial College, London. He has remained at Imperial College since then, except for a sabbatical year in the School of Physics at the University of New South Wales, Australia, and shorter periods at the Indian Institute of Technology, Kanpur, India. He has been a regular visitor at the Maspec Institute (now part of IMEM) in Parma, Italy. He researched the science and technology of semiconducting materials and devices and developed and applied techniques for their characterization in the scanning electron microscope. He is author or co-author of approximately 150 scientific publications and has co-authored or edited five previous books. Ben Yacobi is an Adjunct Professor in the Department of Materials Science and Engineering at the University of Toronto. He received his doctorate in physics from the Hebrew University of Jerusalem in 1975. He held post-doctoral positions at Imperial College, London, and Harvard University, Massachusetts, and technical staff positions at the Solar Energy Research Institute and GTE Laboratories, US. He has worked in several areas of experimental solid-state physics, including the synthesis, applications and characterization of various electronic and photonic materials and devices. He is author or co-author of over ninety scientific publications and four previous books.
